360 degree 100M rotation long range fog sprayer

Sale!

Additional information

Dimensions 1725 × 940 × 2018 cm
Spray distance

100m

Power

68.5Kw

Spray flow L/min

240-280L/min

Fan air volume m³/h

162000m³/h

Fan air pressure /Pa

3635

Rotation angle

0-320°

Maximum dimensions

2430*1680*2550mm

Video

The intelligent controller mainly include: high pressure dust fan, water pump, nozzle, electric control box, remote control receiver, speed reducer, electric hydraulic push rod, rotating mechanism and the base.

Product details

Working principle of spray fan:

First, use the high-pressure water pump to pressurize the water to the micro atomizing nozzle for atomization and then spray it out. Then use the large air pressure and air volume of the professional spray host to send the atomized water to a gradual distance. With the rotation of the rotary mechanism, the atomization area can be covered by a maximum of 360 ° centered on the fan. Use the hydraulic cylinder of the hydraulic pump station to achieve the pitch angle spraying operation of the fan. The water mist can be sprayed to a certain physical height, The atomized micro fog combines with the dust of the air to form particles falling, so as to achieve the effect of dust reduction and air purification.

Technical features of spray fan:

1. Strong skill, long range, wide coverage, high work efficiency, fast spray speed, strong penetration, significant humidification and cooling effects.

2. The effect of dust reduction is good. The fog particles are small and uniform. When they contact with the flying dust, they form a wet fog, which can quickly reduce the dust.

3. The supporting power is flexible, namely, 380V power supply can be used, or generator set (customized for foreign voltage) can be equipped.

4. The installation platform is wide, which can be installed either on the platform or on the transport vehicle.

5. Effectively save water, saving 70% – 80% of water compared with spray guns, sprinklers, etc., and covering a large area.

Advantages of our spray fan products:

1. The air inlet collector is designed with an arc shaped mold for one-time molding. According to the best ratio of arc radius and diameter, the air flow loss is minimized and can be ignored to create a uniform flow field;

2. Sine sawtooth guide vane is adopted at the tail to effectively reduce aerodynamic noise;

3. Streamlined design is adopted for the whole inner cylinder to effectively and evenly accelerate the gas;

4. The air blade adopts the casting aluminum alloy technology, the aerofoil design, the limited aerodynamic performance and the off design performance, the strong air flow matching ability, and the minimal aerodynamic loss;

5. Streamline cover: hemispherical design, which can better ensure the uniformity of the velocity field in front of the entrance;

6. Curved air inlet design (professional mold processing) has small air inlet loss coefficient;

7. Advanced diversion design and manufacturing, shock wave suppression, and improvement of static pressure efficiency;

8. Expanding swinging disc design, effectively restraining wind and fog emission and attenuation;

9. The cone straight cylinder is designed in golden proportion to ensure the highest static pressure conversion efficiency;

10. Drip core barrel design ensures uniform acceleration field.
